Aperçu /Produits/Forage au noyau/Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine

1set / sets par mois
MOQ
negotiable
Prix
Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine
traits Galerie Description de produit Demandez une citation
traits
Caractéristiques
Nom du produit: équipement de forage hydraulique de noyau
Nom: Forage de forage de forage,forage du noyau
taper: Forage au noyau
Usage: échantillon de puits d'eau.
Fonctionnalité: Efficacité de forage élevée, portable, léger
Application: Exploration géologique
Pouvoir: 16.2kw
Vitesse nominale: 2200r / min
Diamètre de perçage: 75-325mm
Profondeur de forage: palette ou selon vos besoins
Diamètre de tige de perceuse: 42 à 60 mm
Dimension (l*l*h): 2700*900*1500 mm
Service après-vente assuré: Assistance en ligne
Poids de levage maximum de l'arbre vertical: 25KN
Pression d'alimentation maximale de l'arbre vertical :: 15kn
Couple de sortie maximum de l'arbre vertical: 15kn
Vitesse de l'arbre vertical (4ème vitesse): 71 142 310 620 tr/min
Déplacement vertical de l'arbre: 450mm
Angle d'immersion du trou: 90-75°
Diamètre du trou final: 75mm
Taille du paquet unique: 2150×880×1560 millimètres
Poids brut unique: 760 kg
Mettre en évidence:

hydraulic core drilling rig machine

,

rotary borehole drilling equipment

,

geological core drilling rig
Informations de base
Lieu d'origine: Zhejiang, Chine
Nom de marque: SANROCK
Certification: CE ISO 9001:2015
Numéro de modèle: SRC200
Conditions de paiement et expédition
Détails d'emballage: Emballage nu pour machines, emballage en boîte en bois pour pièces de rechange, ou demande du client
Délai de livraison: 15-25 jours
Conditions de paiement: LC, D/A, D/P, T/T, Western Union, MoneyGram
Capacité d'approvisionnement: 5000set / sets par mois
Description de produit

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 0

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 1

Hydraulic Exploration Geological Core Drilling Rig – 200m Depth
This hydraulic-powered exploration core drilling rig is specifically engineered for geological survey, mineral prospecting, and geotechnical investigation, with a maximum drilling depth of 200 meters. The fully hydraulic drive system delivers smooth and precise control over rotation speed, feed pressure, and rod handling, ensuring efficient coring in diverse formations including rock, soil, and weathered strata.
Key features include:
High-torque hydraulic rotary head for reliable diamond core drilling (NQ, HQ, BQ).
Hydraulic feed and retraction for accurate bit pressure control and reduced rod wear
Compact and modular design for easy transport and setup in remote or confined sites.
Durable construction suited for continuous operation in tough field conditions.

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 2

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 3

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 4

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 5

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 6

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 7

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 8

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 9

Products Description

Brand Name:SANROCK
Product name :Core Drilling Rig

Name: Core Drilling Machine
Power Type :Diesel

Feature :High Drilling Efficiency,portable,Light Weight
Packaging Details:packing according to customer's requirement.

Model number:Diesel engine
Rated speed:2200r/min
Power:16.2KW
Borehole depth:200M
Pipe diameter:50mm
Opening diameter:75-325mm
Final hole diameter:75mm
Hole dip Angle:90-75°
Gyrator
Vertical shaft speed(4th gear):71,142,310,620 r/min
Vertical shaft travel:450mm
Maximum output torque of vertical shaft:15KN
Maximum feed pressure of vertical shaft:15KN
Maximum lifting weight of vertical shaft:25KN
Single package size:2150×880×1560 mm
Single gross weight:760 kg

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 10

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 11

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 12

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 13

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 14

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 15

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 16

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 17






Company Profile

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 18

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 19

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 20


Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 21

Hydraulic Core Drilling Rig Rotary Borehole Drilling Equipment Geological Core Drilling Rig Machine 22
